Siemens

1MD5 Explosion-Proof Motors

1PS1 Explosion-Proof Motors

1MJ Explosion-Proof Motors

1PS4, 1PS5 Explosion-Proof Motors

1LA-1LG Squirrel-cage motors_2004

1MA7-1MA6 EExe II Squirrel-cage motors_2004

1MJ6-1MJ7-1MJ8 EEx de IIC Squirrel-cage motors_2004

1PP7 Smoke extraction motors_2004

LA8317-4PB40-Z, 315kw, 4pole

315KW - 1488MIN - IMB3 - IP55 -

Siemens motor ,37kw,6pole,type 1LA6 253 6CA10

37KW , 984MIN, SIZE 250M , IMB3 , IP55 ,6POLE

Siemens 1MB1563-1BB22-2JA4, 4Pole,4KW

1MB1563-1BB22-2JA4 XP motor type: 1CD3112B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line Premium Efficiency IE3, 4-pole * size 112M * 4 kW (50 Hz), 4.55 kW (60 Hz) Ex db (eb) IIB T4 version for zone 1 standard color RAL 7030 if no order code is specified for selecting another color.​ Purchase of this product is exclusively governed by the Innomotics T&Cs located at https://www.innomotics.com/ terms-and-conditions 3 AC 50 Hz 230 VD/400 VY * 3 AC 60 Hz 460 VY IM B35, Flange: FF215 (A250) without motor protection terminal box at top

Siemens 1MB1563-1CB23-4JA4, 7.5KW,4Pole

1MB1563-1CB23-4JA4 XP motor type: 1CD3132B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line Premium Efficiency IE3, 4-pole * size 132M * 7.5 kW (50 Hz), 7.5 kW (60 Hz) Ex db (eb) IIB T4 version for zone 1 standard color RAL 7030 if no order code is specified for selecting another color.​ Purchase of this product is exclusively governed by the Innomotics T&Cs located at https://www.innomotics.com/ terms-and-conditions 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B35, flange: FF265 (A300) without motor protection terminal box at top

Siemens 1MB1563-1DB43-4JA4, 15KW,4Pole

1MB1563-1DB43-4JA4 XP motor type: 1CD3164B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line Premium Efficiency IE3, 4-pole * size 160L * 15 kW (50 Hz), 15 kW (60 Hz) Ex db (eb) IIB T4 version for zone 1 standard color RAL 7030 if no order code is specified for selecting another color.​ Purchase of this product is exclusively governed by the Innomotics T&Cs located at https://www.innomotics.com/ terms-and-conditions 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B35, flange: FF300 (A350) without motor protection terminal box at top

Siemens 1LA4560-2CN60-Z 6KV,2Pole,1680KW

SIEMENS » 1LA4560-2CN60 H-COMPACT HV MOTOR ; IP55; IC 411; IM B3 3AC 6KV 50HZ 1680KW POL: 2 ,

Siemens 1LE1502-1EB43-4AA4-Z, 22KW, 4Pole

1LE1502-1EB43-4AA4-Z SD motor type: 1CV1184B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line IE1 in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 4-pole * size 180L, * 22 kW (50 Hz) 25.3 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color.​

Siemens 1LE1002-1DB23-4FA4

1LE1002-1DB23-4FA4 GP motor type: 1AV1162B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) aluminum enclosure Standard Efficiency IE1, in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 4-pole * size 160M, * 11 kW (50 Hz) 12.6 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color.​ 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B 5, flange: FF300 (A350) without motor protection Terminal box at top

Siemens 1LE1502-1EB23-4AA4

1LE1502-1EB23-4AA4 SD motor type: 1CV1182B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line IE1 in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 4-pole * size 180M, * 18.5 kW (50 Hz) 21.3 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color.​ Purchase of this product is exclusively governed by the Innomotics T&Cs located at https://www.innomotics.com/ terms-and-conditions 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B 3, without motor protection Terminal box at top

Siemens 1LE1502-2AB53-4AA4-Z

1LE1502-2AB53-4AA4-Z SD motor type: 1CV1205B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line IE1 in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 4-pole * size 200L, * 30 kW (50 Hz) 34.5 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color.​

Siemens 1LE1002-1CA13-4AA4-Z

1LE1002-1CA13-4AA4-Z GP motor type: 1AV1131A low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) aluminum enclosure Standard Efficiency IE1, in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 2-pole * size 132S, * 7.5 kW (50 Hz) 8.6 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color

Siemens 1LE1502-2BB03-4AA4

1LE1502-2BB03-4AA4 SD motor type: 1CV1220B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line IE1 in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 4-pole * size 225S * 37 kW (50 Hz) 42.5 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color.​ 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B 3, without motor protection Terminal box at top

Siemens 1LE1002-1AB42-2AA4

1LE1002-1AB42-2AA4 GP motor type: 1AV1104B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) aluminum enclosure Standard Efficiency IE1, in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 4-pole * size 100L * 2.2 kW (50 Hz) 2.55 kW (60 Hz) 3 AC 50 Hz 230 VD/400 VY * 3 AC 60 Hz 460 VY IM B 3, without motor protection Terminal box at top

Siemens 1LE1502-2DB23-4AA4

1LE1502-2DB23-4AA4 SD motor type: 1CV1282B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line IE1 in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 4-pole * size 280M * 90 kW (50 Hz) 104 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color.​ 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B 3, without motor protection Terminal box at top

Siemens 1LE1502-3AA53-4AB4

1LE1502-3AA53-4AB4 SD motor type: 1CV1315A low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line IE1 in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 2-pole * size 315L, * 200 kW (50 Hz) 224 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color.​ 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B 3, 3 PTC thermistors for disconnection (2 terminals) Terminal box at top

Siemens 1LE1502-2DA23-4AA4

1LE1502-2DA23-4AA4 SD motor type: 1CV1282A low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line IE1 in EEA: minimum efficiency according to (EU) 2019/1781 is IE3 (as of 01.07.2021) 2-pole * size 280M * 90 kW (50 Hz) 101 kW (60 Hz) standard color RAL 7030 if no order code is specified for selecting another color.​ Purchase of this product is exclusively governed by the Innomotics T&Cs located at https://www.innomotics.com/ terms-and-conditions 3 AC 50 Hz 400 VD/690 VY * 3 AC 60 Hz 460 VD IM B 3, without motor protection Terminal box at top
